Ống thép hàn

Black hollow section Rectangular pipe cold rolled pre galvanized welded square rectangular steel pipe T(mm) 0.6 0.7 0.8 0.9 1.0 1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 10*10 12*12 16*16 19*19 20*20 25*25 30*30 32*32 38*38 40*40 50*50 60*60 63.5*63.5 70*70 75*75 80*80 90*90 100*100 120*120 125*125 150*150 200*200 300*300 350*350 400*400 T(mm) 2.0 2.25 2.50 2.75 3.00 3.25 3.50 3.75 4.00 4_6 6_8 8_12 10*10 12*12 16*16 19*19 20*20 25*25 30*30 32*32 38*38 40*40 50*50 60*60 63.5*63.5

Products Description TORICH GB/T24187 BHG1 Precision Single Welded Carbon Steel Coil Tubes for Condenser Standard GB/T24187 Material Q195 Q215 Q235 Q295 Q345 Size WT: 0.5-1.2mm; OD: 3.18-18mm; Length: 1-200m Processing W-H W-C Sureface Bright ,Copper Plated, Galvanized Or Customers'requirements Applications Condenser, evaporator, cooler tube fuel pipe of refrigeration,automobile and electric appliance industrial Test Tension Test, Flaring Test, Flange Test, Reverse Test,

JIS G3452 SGP Welded Carbon Steel Pipes for Ordinary Piping Application for ordinary piping Diameter: 5-420mm, Wall thickness: 0.5-50mm Length: 12mmax Grade: SGP Standard: JISG3452 Black pipe: without zinc coating Galvanized pipe: with zinc coating Produce method:ERW Steel Grade:SGP Relevant standard: KSD3507, ASTMA53, API5L, DIN2440, DIN2441, BS1387, BS3601, JISB0203, JISB0253, JISB2301 Black pipe without zinc coating Galvanized pipe with zinc coating CHEMICAL COMPOSITION

JASO M101 Nylon12 Coating Single Wall Bundy Tube 1. Standard SAE J526 Welded low-carbon tubing EN10305-6 Welded cold drawn tubes from hydraulic and pneumatic power systems ASTM A254 Copper-brazed steel tubing 2. Steel Grade BHG1, SPCC, SPCD, SPCEN, ST14, ST15, ST16, DC04, DC05, DC06 3. Heat Treatment BK or NBK 4. Specification O D/ mm 4 4.2 4.76 6 6.35 7.8 8 9.52 W T 0.5-1.0mm (0.5-0.7mm common WT) Tolerance ±0.05mm Length 180Kg/coil; 700-1000m/coil; per customer’s request 5.

SAE J525 Welded Cold Drawn Low Carbon Steel Tubing Annealed for Bending and Flaring Applications: for Bending and Flaring to Auto Parts Quick Detail: Size range: O.D.:6-350mm W.T.:1-15mm L: According to customer Order Grade: Low Carbon Steel Manufacture and Production: ERW+ DOM The tubing is made from flat-rolled steel shaped into a tubular form, the edges of which are joined and fused together by electric-resistance welding. After forming and welding, the tubing shall be

ASTM A513 Low Carbon Electric Resistance Welded (ERW) Steel Tube For Truck Exhaust System Product Overview ASTM A513 low carbon ERW steel tube is a cost-effective welded mechanical tubing product designed specifically for truck exhaust system applications. This tubing is ideal for straight exhaust sections, intermediate pipes, tailpipe assemblies, muffler inlet/outlet tubes, and fabricated exhaust connectors. Manufactured from low-carbon steel strip using electric resistance

ASTM A214 is a specification that covers minimum-wall-thickness, electric-resistance-welded, carbon steel tubes to be used for heat exchangers, condensers, and similar heat-transfer apparatus. These tubes are commonly used in boilers, superheaters, and air coolers. Material and Specification The material used in ASTM A214 is carbon steel, and the tubes are electric-resistance-welded. The specification covers a range of sizes and thicknesses, as shown in the table below.

SA178 Grade A / Grade C / Grade D Electric-Resistance-Welded Carbon & Carbon-Manganese Steel Tube for Heat Exchangers Material SA178 (equivalent to ASTM A178) is a minimum-wall-thickness electric-resistance-welded (ERW) tubing product made from carbon steel (Grade A, Grade C) and carbon-manganese steel (Grade D) . It is widely specified for boiler tubes, boiler flues, superheater flues, and safe ends , and is also commonly selected for heat-transfer service where stable weld

SAE J526 PVF/ Copper Coating Single Wall Bundy Tube For Brake System 1. Standard SAE J526 Welded low-carbon tubing EN10305-6 Welded cold drawn tubes from hydraulic and pneumatic power systems ASTM A254 Copper-brazed steel tubing 2. Steel Grade BHG1, SPCC, SPCD, SPCEN, ST14, ST15, ST16, DC04, DC05, DC06 3. Heat Treatment BK or NBK 4. Specification O D/ mm 4 4.2 4.76 6 6.35 7.8 8 9.52 W T 0.5-1.0mm (0.5-0.7mm common WT) Tolerance ±0.05mm Length 180Kg/coil; 700-1000m/coil; per
