Dàn ống thép

DIN 2391 Precision Seamless Mechanical Cold Drawn Carbon Steel Tubes Product Description: 16X1 20X2 DIN2391 St 30Si, St 30Al, ST35, ST37.4, ST52CDS DOM Steel Tube DIN2393 ST35 CDW DOM Steel Tube Appilcations for machinery use/ for Auto industry/ for hydraulic and pneumatic power system Outside Diameter 5 - 420 mm Wall Thickness 0.5 - 50 mm Length Max12000 mm Steel Grade/Steel Material: St 30Si,St 30Al, ST35, ST37.4, ST52 Product Details: Company Information: FAQ Q: Are you

DIN2391 Cold Drawn Precision Seamless Steel Pipes For Auto Industry And Oil Cylinder Applications: For Auto industry For machinery use Oil Cylinder Tube Motorcycle shock absorber Size range: O.D. 5-420mm W.T. 0.5-50mm Length max 12000mm Steel Grade and Chemical Requirement: Product Show: FAQ What is your Payment Term? 1.T/T: 30% deposit in advance, the balance 70% paid before shipment 2.30% down payment, the balance 70% paid against L/C at sight 3.Upon negotiation Who are

Square and Rectangle Tubing ASTM A500 Welded and Seamless Carbon Structural Tubes Applications: for construction of bridges, and buildings, and for general structural purposes Size Range Square tubes Rectangle tubes O.D. 5 - 420 mm 20 - 30 to 400 - 600 W.T. 0.5 - 50 mm 1 - 24 mm L Max 12000 mm Max 12000 mm Steel Grade and Chemical Compositions: Element Grade A, B and D Grade C Heat Analysis Product Analysis Heat Analysis Product Analysis Carbon, max 0.26 0.3 0.23 0.27

Seamless Tube Machining Steel Tube 41CR4 41CR S45C 45# Grade Precision Steel Tubes CDW Seamless Tube Machining Steel Tube 41CR4 41CR S45C 45# Grade Seamless Mechanical Tube (SMT)/Seamless Hydraulic Tube (SHT) Size list: OD 16 X ID 5.50mm OD 18 X ID 5.45mm OD 20 X ID 6.05mm OD 30 X ID 6.35mm OD39.5X ID7.5mm 20Cr: C: 0.18-0.24 Si: 0.17-0.37 Mn: 0.50-0.80 P: min 0.035 S: 0.035 Cr: 0.70-1.00 Ni: 0.30 Cu: 0.30 Mo: 0.15 40Cr: C: 0.37-0.44 Si: 0.17-0.37 Mn: 0.50-0.80 P: 0.035 S: 0

EN10216 - 2 & DIN17175 Boiler and Pressure System Seamless Steel Tubes Description: Appilcations for manufacturing pipelines of boilers, vessel quipment Outside Diameter 5 - 420mm Wall Thickness 0.5 - 50mm Length Max12000mm Steel, Chemical Composition & EN10216-2: Grade C Si Mn P S Cr Mo 195GH ≤0.13 ≤0.35 ≤0.70 ≤0.025 ≤0.020 ≤0.30 ≤0.08 P235GH ≤0.16 ≤0.35 ≤1.20 ≤0.025 ≤0.020 ≤0.30 ≤0.08 P265GH ≤0.20 ≤0.40 ≤1.40 ≤0.025 ≤0.020 ≤0.30 ≤0.08 20MnNb6 ≤0.22 0.15-0.35 1.00-1.50 ≤0

EN10216-2& DIN17175 Seamless Steel Tubes For Pressure Purposes-Technical Delivery Conditions Applications: For manufacturing pipelines of boilers Vessel equipment Size range: O.D. 5-420mm W.T. 0.5-50mm Length max12000mm Steel Grade, Chemical Compositions and Mechanical Property: Standard Grade Chemical Compostion Mechanical Property C Si Mn P S Cr Mo Mpa Mpa L T EN10216-2 195GH ≤0.13 ≤0.35 ≤0.70 ≤0.025 ≤0.020 ≤0.30 ≤0.08 320-440 ≥195 ≥27 ≥25 P235GH ≤0.16 ≤0.35 ≤1.20 ≤0.025 ≤0

17mm High Precision Seamless Steel Tube 17mm High Precision Seamless Steel Tube 1.Quick Detail: Black Phosphated Hydraulic Tubes with High Precision EN10305-1, EN10305-4, DIN2391, E235, E355, ST37.0, ST44.0, ST52.0 Steel Pipes with high precision for Hydraulic Systems Black Phosphating 2.Production process: DIN series tubes, cold drawn and bright annealed precision seamless steel tube is used as the tube to be phosphated. The phosphorization is realized with the imported

Torich 210mm OD EN10305-4 Precision Carbon Steel Tube Seamless Carbon Steel Pipe Brief introduction: Product name 210mm OD EN10305-4 Precision Carbon Steel Tube Seamless Carbon Steel Pipe Standard EN10305-2, EN10305-4,JIS-G3445,DIN2393 Size OD:5-210mm WT:1-25mm Usage Gas Spring,Automobile Shock Absorber Cylinder,Motorcycle Front Fork,Automobile Shock Absorber Reservior. Shape Round Type Seamless Manufacture Cold drawn Packing Usually bundles in cartons The tubes shall be

Torich 12m Length 415mpa 45# High Precision Tube DIN 2440 St33 Seamless Steel Tubes Introduction: Product name: Torich DIN 2440 St33 Tubo Seamless Steel Tubes Carbon Pipes Standard: DIN 2440 Technical: Hot rolled Size Range: OD: 6-1016mm WT: 2.87-150mm Length:5-12m Application: Mechanical industry, construction,etc Section shape: Round Surface tratement Black/no coating Application: Hot rolled structural tube, fluid tube, medium and low boiler Material: 10 # 20 # 45#
